SylWrap Cast Iron Pipe Repair Kit

The SylWrap Cast Iron Pipe Repair Kit is a specialist kit for use on cracked, split and leaking cast iron pipework where there is no pressure. It enables permanent repair in under 30 minutes to drain, waste, soil and supply pipes between 32mm and 150mm, matching standard cast iron pipe diameters.

It follows the same format as a SylWrap Standard Pipe Repair Kit, but contains additional CrackSeal Sealant for making faster, easier repairs to longitudinal cracks and splits in cast iron.

Repairs are pressure resistant to 30 bar and temperature resistant to 200ºC. The Kit enables effective repairs to be made around elbow joints, tee joints and around sections of difficult-to-access pipes in confined spaces. It offers a flexible alternative to heavy, bulky pipe repair clamps.

No operational training is required before using the Cast Iron Pipe Repair Kit – simply follow the straightforward instructions provided. Repairs can be made to both domestic and industrial pipework in exterior or interior settings at a fraction of the cost of pipe replacement.

For users who are regularly repairing cast iron pipework, Sylmasta also manufacture the SylWrap Drain & Waste Pipe Repair Kit. It contains enough products to make multiple repairs to cast iron and plastic pipes, even when water is leaking through.

The Drain & Waste Pipe Repair Kit comes in a robust red card which is easily stored on-site or on a van, minimising disruption by enabling contractors to carry everything needed to repair leaks as soon as they are identified.

About

SylWrap Cast Iron Pipe Repair Kit details

The Cast Iron Pipe Repair Kit contains Superfast Steel Epoxy Putty Stick, CrackSeal Sealant and SylWrap HD Pipe Repair Bandage.

Superfast Steel is used to seal the small holes and cracks. The required amount of putty is mixed by hand until it turns a uniform colour. It is then pushed into the hole or crack, where it will harden in around 5-10 minutes to fill the damage with a watertight material.

CrackSeal Sealant seals longer cracks and splits in cast iron pipework. Using a standard sealant applicator gun (not provided as part of the Kit), it is extruded directly into the crack until fully filled. CrackSeal sets almost instantly, even on wet surfaces.

Once the crack has been sealed, the repair is completed by overwrapping with SylWrap Pipe Repair Bandage. SylWrap is a fibreglass repair wrap with a water-activated resin.

When wrapped and smoothed over the pipe, it will set rock-hard to provide an impact resistant, protective layer over the initial sealant for a permanent, reinforced repair.

Superfast Steel and SylWrap HD both have WRAS Approval, meaning they are certified as safe to use on pipes carrying drink water. CrackSeal does not have WRAS Approval and cannot be used with potable water.

Benefits of a SylWrap Cast Iron Pipe Repair Kit

  • Seals holes, cracks and longitudinal splits in under 30 minutes
  • Repairs can be made at a fraction of the cost compared with replacement
  • Easy to use with no operational training required – just follow the instructions provided
  • Superfast Steel and SylWrap HD make WRAS approved repairs

Applications

  • Cast iron waste, drain and soil pipe repairs
  • Sealing leaking rainwater stacks
  • Repairing pipework in hospitals, office blocks, car parks and other public buildings
  • Cast iron gutter repair

Technical Data

Data
SylWrap Work Time2–5 minutes
Functional Cure30–45 minutes
Full Cure24 hours
Cured Material Life10–20 years
Max Service Temp200°C / 390°F
Max Pressure Resistance30 bar

Product Codes

Please see Pipe Size Guide Tab for SylWrap Cast Iron Pipe Repair Kit product codes

TDS Downloads

Download SylWrap Cast Iron Pipe Repair Kit TDS
Pipe Size Guide

SylWrap Cast Iron Pipe Repair Kit Size Guide

The Size Guide lists the quantity of SylWrap Pipe Repair Bandage and CrackSeal Sealant each Drain Cast Iron Pipe Repair Kit contains and the pipe diameters the Kit can be used with.

SYL-CAST-32-150 is an all-purpose Kit containing enough CrackSeal and different sized SylWrap HD Bandages to cover all diameters and make multiple repairs. All Kits contain 1 x 114g Superfast Steel Epoxy Putty.

WordPress Tables Plugin
Case Studies

SylWrap Cast Iron Pipe Repair Kit Case Studies

Videos

SylWrap Cast Iron Pipe Repair Kit Videos

Repair of 450mm long crack in cast iron pipe

Demonstration video filmed at Sylmasta HQ showing CrackSeal and SylWrap HD Pipe Repair Bandage permanently sealing a cracked cast iron pipe in under 15 minutes.

A 450mm long split was cut into the pipe. After surface preparation, CrackSeal was extruded directly into the crack before overwrapping with SylWrap HD for added protection and reinforcement.

Following the repair, a bucket of water was poured into the pipe. The water was easily contained, showcasing the strength of the repair.

Please use the form to enquire about the price and availability of the
SylWrap Cast Iron Pipe Repair Kit

Related Leak Repair Kits

SylWrap Drain & Waste Pipe Repair Kit

Specialist Kit to repair multiple splits in cracked cast iron and plastic pipework. It is designed for end-users like facilities management teams who are regularly required to repair drain, waste and soil pipes.

Live Leaks: Yes
Number of Repairs: Multiple
Pressure Resistance: Up to 30 bar
Temperature Resistance: Up to 200ºC

SylWrap Pipe Repair Contractor Case

For regular users like water companies, the Contractor Case is stored on-site or on-the-van for fast response as soon as leaks are identified. It makes up to six WRAS approved, permanent live leak repairs.

Live Leaks: Yes
Number of Repairs: Multiple
Pressure Resistance: Up to 30 bar
Temperature Resistance: Up to 200ºC

SylWrap Universal Pipe Repair Kit

The Universal Pipe Repair Kit contains Superfast Epoxy Putty, Wrap & Seal and SylWrap Bandage. It makes a single, WRAS approved, permanent repair to live leaks where pressure cannot be turned off.

Live Leaks: Yes
Number of Repairs: One
Pressure Resistance: Up to 30 bar
Temperature Resistance: Up to 200ºC
